3528 RGBW LED Wall Washer Light 10° 15° 30° 60° 10x60° 30P10° 24V

  • 1
  • 2
  • 3

MOQ : 100M

Model Number : 3528

Place of Origin : CHINA

Brand Name : RELIGHT

Certification : CE,ETL,UL

Price : Contact us to get best price

Delivery Time : 2-3weeks

Payment Terms : T/T

Supply Ability : 10000M/M

Waterproof  grade : IP67

Working temperature : -25~+60℃

Features : long lasting durability

Technologies : ON/OFF, DMX

Contact Now


Features

1. 3528 fully covered rubber wall washing lamp, the bending radius is 150mmProduct cutting unit: 250mm
2. Multi-angle selection 10°, 15°, 30°, 60°, 10x60°, 30P10°...
3. good wall washing effect, high irradiation intensity, uniform lightno color difference,
4. Monochrome, two-color, RGB, RGBW, SPl, DMX program series is complete
5. Waterproof grade lP67
6. 5 years warranty

Technologies: ON/OFF, DMX


Application:

This product is suitable for use in engineering projects, outdoorlighting, decorative lighting in buildings, hotels, shopping malls, etc.


3528 RGBW LED Wall Washer Light 10° 15° 30° 60° 10x60° 30P10° 24V


Product Specification

P/N LED Quantity CCT
(K)
CRI LEDs/m LUMENS (lm/m) Vf (V.) Current (mA/M) Power (W/M) Cut Length (MM) Max Run (M)
RL-FV2422024353530-DMX-RGBW-830-FWD3528 3535 R 80/90 24 165 24 1250 30 250 5
G 405
B 98
3000 450

Other Specifications

Protection grade IP67
Working temperature(°C) -25~+60
Storage environment temperature (°C) -25~+70
Standard length 5
Maximum cascade length(m) 5
weight /

Remark

  • The test environment temperature is 25±2°C;

  • The above data are typical values, the actual parameters of the product may be different from the typical data; the data is subject to change without notice;

  • The above "/" means that this parameter is not required for the time being.

Applied Standards

CE ROHS cULus LISTED ETL Intertek CB Reach UKCA
